Prime matte
Frame Specifications
ONE-PIECE Ti-6Al-4V |
Head Tube Seat Tube Bottom Bracket |
Spiral Titanium Tubing |
Ti-3Al-2.5V (Down Tube / Seat Tube / Right Chainstay) Ti-6Al-4V (Custom) |
Taper Head Tube |
1-1/8”*1-1/8” Integrated Headset IS41/28.6 IS41/30 45°*45° |
Seatpost Diameter |
Ø27.2 |
Bottom Bracket |
English threaded BB |
Max Tire Size |
25C |
Surface |
Sandblasting |
Technology
ONE-PIECE 6-4 Titanium
The one-piece forming process with 6-4 titanium alloy has enhanced the strength and rigidity performance of the frame.
Titanium Spiral Tube
The internal spiral structure of the pipe enhances its resistance to bending and torsional forces. It means there is no waste of your every single pedal.
Smooth Welding
The special design of the weld joints ensures a 100% complete penetration during welding, resulting in a smooth and visually appealing finish.
Integrated Cable Entrance
Unlike typical plastic cable entrances, we have retained the titanium alloy integrated cable entrance, ensuring a more unified and aesthetically pleasing appearance (available for SHIMANO Di2 / SRAM E-TAP/ mechanic shifting).
Geometry
| Frame size | S | M | L | |
| A | Seat tube length | 470 | 490 | 520 |
| B | Effective Top tube | 506 | 524 | 539 |
| C | Head tube length | 105 | 120 | 135 |
| D | Head tube angle | 70.5 | 71.5 | 72 |
| E | Seat tube angle | 74.5 | 74.0 | 73.5 |
| F | Chainstay length | 405 | 405 | 405 |
| G | Wheel base | 966 | 971 | 977.5 |
| H | Stack | 499 | 495 | 532 |
| I | Reach | 368 | 376 | 382 |
Fork Length:370mm BB Drop: 68mm
